Model |
MIC-DPP-80(B) |
MIC-DPP-150(B) |
MIC-DPP-250 |
MIC-DPP-260S |
MIC-DPP-260S-II |
MIC-DPP-260D |
MIC-DPP-420S |
MIC-DPP-420S-II |
Traction control system |
|
|
Mechanical cam traction |
Servo motor traction |
Servo motor traction and traction lengthened |
Servo motor traction and traction lengthened |
|
|
Stations |
|
|
Four stations: forming, heating, perforation, punching |
Four stations: forming, heating, perforation, punching |
Four stations: forming, heating, perforation, punching |
Five stations: forming, heating, embossing, perforation, punching |
|
|
Max. Forming Area And Depth (mm) |
Al-Al:80*100*14 Al-Plastic:80*100*26 |
Al-Al:130*130*14 Al-Plastic:130*130*26 |
240*150*26 |
240*150*26 |
240*180*45 SPECIAL DEPTH MODEL |
240*180*26 |
390*150*26 |
390*150*26 |
Cutting Frequency (t/min) |
Al-Al: 10-20 Al-Plastic: 10-40 |
Al-Al: 10-25 Al-Plastic: 10-50 |
AL-AL: 10-25 AL/PAPER-PVC: 10-50 |
AL-AL: 10-25 AL/PAPER-PVC: 10-50 |
AL-AL: 10-25 AL/PAPER-PVC: 10-50 |
AL-AL: 10-25 AL-PVC/PAPER: 10-50 |
10-35 |
10-35 |
Travel Range (mm) |
40-80 |
60-130 |
40-150 |
40-150 |
20-180 |
20-180 |
40-160 |
40-160 |
Air Pressure (Mpa) |
0.4-0.6 |
0.4-0.6 |
0.4-0.7 |
0.4-0.7 |
0.4-0.7 |
0.4-0.7 |
0.4-0.7 |
0.4-0.7 |
Air Supply |
≥0.1m³/min |
≥0.2m³/min |
≥0.35m³/min |
≥0.35m³/min |
≥0.35m³/min |
≥0.35m³/min |
≥0.35m³/min |
≥0.35m³/min |
Total Power |
380V/220V 50Hz 3.5kw |
380V/220V 50Hz 3.6kw |
380V/220V 50Hz 6.4kw |
380V/220V 50Hz 6.4kw |
380V/220V 50Hz 6.4kw |
380V/220V 50Hz 7.6kw |
380V/220V 50Hz 9.7kw |
380V/220V 50Hz 22kw |
Main Motor Power (kw) |
0.55 |
0.75 |
1.5 |
1.5 |
1.5 |
1.5 |
2.2 |
2.2 |
Material Width (mm) |
0.25-0.5*100 (PVC) 0.02-0.035*100 (ALU FOIL) |
0.25-0.5*100 (PVC) 0.02-0.035*100 (ALU FOIL) |
0.25-0.5*260 (PVC) 0.02-0.035*260 (ALU FOIL) |
0.25-0.5*260 (PVC) 0.02-0.035*260 (ALU FOIL) |
0.25-0.5*260 (PVC) 0.02-0.035*260 (ALU FOIL) |
0.25-0.5*260 (PVC) 0.02-0.035*260 (ALU FOIL) |
0.25-0.5*420 (PVC) 0.02-0.035*420 (ALU FOIL) |
0.25-0.5*420 (PVC) 0.02-0.035*420 (ALU FOIL) |
Mould Cooling |
Tap water or circulating water |
|||||||
Overall Dimensions (mm) |
1400*460*950 (L*W*H) |
2350*560*1410 (L*W*H) |
3000*730*1600 (L*W*H) |
3000*730*1600 (L*W*H) |
3500*730*1600 (L*W*H) |
3900*730*1600 (L*W*H) |
4000*950*1600 (L*W*H) |
4500*950*1600 (L*W*H) |
Weight (kg) |
450 |
750 |
1300 |
1300 |
1400 |
1600 |
1800 |
2000 |
Introduction to Blister Packing Machines from Micmachinery
Features of Our Blister Packing Machines
Automatic Blister Packing Machine: Our automatic blister packing machines integrate advanced automation for seamless operation, reducing labor costs while maintaining packaging accuracy and speed. These machines are ideal for large-scale production, ensuring that each package meets the highest standards of quality.
Alu Blister Packing Machine: The alu blister machine is designed for aluminum-based packaging, ideal for pharmaceuticals that require a protective seal. With alu alu blister packing machine options, you can choose the best fit for your packaging needs, whether it's for high-value products or enhanced protection from external factors.
Thermoforming Blister Packaging Machine: Our thermoforming blister packaging machines offer flexibility in material usage, allowing you to choose between PVC, PET, or other materials to form the perfect blister package. This machine is perfect for the pharma blister packaging machine industry, offering durability and high-quality seals for even the most sensitive products.
Blister Pack Sealing Machine: For the ultimate seal, our blister pack sealing machine ensures a tight, tamper-proof seal that is critical in the pharmaceutical and medical device industries. The precision of our sealing system guarantees that your products are securely packaged, reducing the risk of contamination or damage during transport.
Fully Automatic Blister Packing Machine: For those looking for a hands-off solution, our fully automatic blister packing machines deliver speed and consistency. These machines are perfect for high-volume production, reducing the need for manual intervention while improving overall efficiency.
Blister Packaging Equipment for Pharma: In the blister packaging machine pharmaceutical industry, reliability and compliance with safety standards are paramount. Our blister packaging machines for pharmacy are built to meet stringent regulatory requirements, ensuring that your products are not only well-packaged but also secure for consumer use.
Customization and Pricing
In addition to our customization options, we offer competitive blister packing machine prices without compromising on quality. Our customers benefit from our transparent pricing and high-quality machinery, ensuring that they get the best value for their investment. For those seeking more affordable options, we also offer blister packaging machine for sale at budget-friendly rates, without compromising on functionality or durability.
Why Choose Micmachinery?
Whether you need a capsule blister packaging machine, a liquid blister packing machine, or a blister packaging machine for tablet solutions, Micmachinery is here to help. Our extensive range of blister packaging machines for pharmacy and other industries ensures that your packaging needs are met with the utmost professionalism and quality.
