Gantry Palletizer JYMD30: Elevate Your Palletizing Efficiency


At Micmachinery, we are excited to unveil the Gantry Palletizer JYMD30, an innovative solution that redefines palletizing efficiency in modern manufacturing. As a leader in palletising equipment, we are committed to providing advanced technology that enhances productivity and reliability in your operations.


The JYMD30 is designed with a high-speed operation that allows it to manage large volumes of products effortlessly, making it ideal for high-demand production lines. Its robust robotic palletizing system minimizes manual intervention, which not only reduces labor costs but also ensures consistent accuracy in product handling. Whether you’re dealing with boxes, bags, or bottles, the JYMD30’s flexible design accommodates a variety of product shapes and sizes, catering to diverse industries, from food and beverage to pharmaceuticals.

One of the standout features of the JYMD30 is its compact and intelligent gantry structure, which requires minimal floor space. This space-efficient design seamlessly integrates into facilities with limited operational areas, maximizing productivity without compromising performance. The user-friendly control panel further enhances its appeal, allowing operators to easily set parameters and monitor processes, ensuring a smooth and efficient workflow.

Built with high-quality materials, the JYMD30 is engineered for durability and reliability. Its robust construction withstands the rigors of continuous operation, reducing maintenance needs and ensuring long-lasting performance. Additionally, the machine can be tailored to meet specific production requirements, offering customizable configurations that optimize the palletizing process for your unique operational demands.

The Gantry Palletizer JYMD30 also integrates seamlessly with existing conveyor systems and other machinery, creating a cohesive workflow that enhances overall efficiency in your production environment.

In conclusion, the Gantry Palletizer JYMD30 is not just a piece of machinery; it’s a transformative solution designed to elevate your palletizing operations. With its high-speed capabilities, advanced robotic palletizing system, and versatility, it stands out as a premier choice in the realm of palletising equipment. At Micmachinery, we are dedicated to helping businesses maximize their efficiency and achieve their production goals.

For more information about the Gantry Palletizer JYMD30 and how it can revolutionize your palletizing process, contact us today!

Name

Model

Quantity

Unit Price (Yuan)

Total (Yuan)

Remarks

Gantry Palletizer

JYMD30

1set

Differential part

1set

14000

14000

Including one set of motor with brake + reducer + inverter, 8 sets of bearings, 4 sets of shafts with outer diameter of 80, one set of frame sheet metal, etc.

Compilation station part

1set

41000

41000

Including one set of motor + reducer + inverter, one set of servo motor + reducer + servo driver, including 70 stainless steel rollers + steel structure + 3 optical axes, 6 sets of cylinders, 4 sets of synchronous wheels, 2 sets of synchronous belts, 2 sets of lights, 2 sets of cold-drawn steel, etc.

Main lifting part

1set

58000

58000

Including one set of 4.4kw motor + reducer + servo controller, one set of motor + reducer + inverter, 2 sets of sprocket chains and drag chains, 24 rollers, sheet metal and steel structure, 5 sets of cylinders, 6 sets of sprockets, 2 sets of cold-drawn steel, etc.

Pallet machine

1set

30000

30000

4 sets of cold-drawn steel, one set of motor + reducer + inverter, steel structure and sheet metal, 2 sets of cylinders

Pallet machine conveyor line

1set

40000

40000

Including 86 80 OD rollers, 3 sets of motors + reducers + inverters, one set of sheet metal and brackets, 2 sets of cylinders, and 35 chains

electric cabinet and control system

1set

32000

32000

Including one set of electric cabinet, PLC relay module, cable, pneumatic components, wire duct, etc.

Total price of the stacking machine

215000

Ball conveyor stainless steel (including motor inverter)

10m

Conveying 90° bend

1set

Fully automatic wrapping machine

1set

59000

59000

Fully automatic wrapping machine roller conveyor

3m

4000

12000

Safety guardrail

1set

Giveaway

Total including tax

286000

Standard capacity:

24 bottles (500ml) up to 33 packs/minute (max)

12 bottles (1000ml) up to 33 packs/minute (max)

6 bottles (1500ml) up to 33 packs/minute (max)

Note: The palletizing speed is related to the pallet size and the grouping form of each layer.

Film package shape: 4*6 shape 24 bottles/package (500ml) 3*4 shape 12 bottles/package (1500ml) 2*3 shape 6 bottles/package (1500ml)

Operation mode:

human-machine interface, free switching of palletizing mode

Maximum load per layer:

260KG

Maximum load per pallet:

1600KG

Maximum stacking height:

1700MM (excluding pallet height) (3*4 shape 12 bottles/package (1500ml), stacking 5 layers) (4*6 shape 24 bottles/package (500ml) can be stacked 7 layers) can be automatically adjusted according to product height.

Maximum size of pallet:

1300*1100MM 1200*1100MM 1100*1000MM

1200*1000MM 1200*800mm (can be customized)

Motor power supply/power:

three-phase five-wire, AC 380V/50HZ, 10KW

Control voltage:

DC 24V

Air consumption:

500NL/MIN (air usage: 6-8KG/CM2)

Air pipe interface size Φ16

Equipment size:

(L)10000MM×(W)6500MM×(H)400MM

Environmental conditions:

Temperature 0-40

Humidity 40-95%

Equipment weight:

7500KG

Two servo motors (1 4.4kw, 1.3kw 2 sets)

6 sets of reduction motors

No.

RLMD30

Configuration

Technology

Brand

1

plc

China

Huichuan

2

touch screen

China

Huichuan

3

variable frequency speed regulato

China

Huichuan

4

solenoid valve

TAIWAN

AirTac

5

cylinder

TAIWAN

AirTac

6

proximity electronic switch

Japan

OMRON

7

limit switch

Japan

OMRON

8

air switch

TAIWAN

AirTac

9

contactor r

France

Schneider

10

transmission belt

China

Shenzhou

11

switching power supply

France

Schneider

12

miniature circuit breaker

France

Schneider

13

intermediate relay

France

Schneider

14

servo motor

C-japan

Huichuan

15

reduction motor

China

Hengchi

16

main frame

China

cold rolled carbon steel

17

bearing

Japan

IKO

18

bearing with seat

China

Luoyang
